Pump: upgraded from gear to rotary vane pump (increases to 9 bars in 1 second, is consistent & tuneable). Can be direct plumb or draw from a water tank, within 1 meter of the machine.
Power switch; located internally for safe, quick repair scenarios.
Power save: “Interrupt Power Save” by moving actuator will interrupt “Power Save” and begin the heat-up process.
Similarly, if machine is set to “Sleep” and enter “Power Save” mode at 3PM––moving the actuator initiates machine
heat-up cycle. Machine automatically re-enters “Power Save” mode 1 hour after the last drink was made.
Shot counter: one resettable shot counter.
A new heating system lets the machine heat both boilers simultaneously for better performance. To take full advantage of the
new system’s capabilities, Slayer developed a new circuit board to drive an additional solid state relay (SSR) and run a new PID algorithm. Note 220 Volt Models obviously have much greater system heat performance,
PID Setting: the machine’s PID algorithm has been completely re-written, resulting in a dramatic increase in
temperature stability and machine performance. These settings are now tuned and locked; in the past they were
available to the end user to adjust, this is no longer necessary and the option has been removed from the menu.
Upgraded parts; water inlet changed from plastic to copper; upgraded composition of rubber on 3-way vent tube
to alleviate oxidation and cracking; all solenoids are forged body to prevent any leaks as result of bulging o-rings.
Ultimately, these upgrades were made to reduce the cost of maintenance needed on the machine.
Reservoir Drip Tray & Removable Drip Tray are available as an accessory to the stock machine.
