ROCKET CONTROL BOARDS
| MACHINE S/N | MODEL | BOARD CODE | NOTES |
| GIOTTO TYPE V | A199904525 | ||
| MOZZAFIATO TYPE V | A199904525 | ||
| GIOTTO EVOLUZIONE R | A199904525 | ||
| MOZZAFIATO EVOLUZIONE R | A199904525 | ||
| FROM D1915… | GIOTTO CRONOMETRO V | A199906657 | |
| FROM D1915… | MOZZAFIATO CRONOMETRO V | A199906657 | |
| GIOTTO CRONOMETRO V | NON ECO MODE | REMOVE BRIDGE FROM CONTROL BOARD A199906657 | |
| MOZZAFIATO CRONOMETRO V | NON ECO MODE | REMOVE BRIDGE FROM CONTROL BOARD A199906657 | |
| FROM D1915… | GIOTTO CRONOMETRO R | A199906657 | |
| FROM D1915… | MOZZAFIATO CRONOMETRO R | A199906657 | |
| GIOTTO CRONOMETRO R | NON ECO MODE | REMOVE BRIDGE FROM CONTROL BOARD A199906657 | |
| MOZZAFIATO CRONOMETRO R | NON ECO MODE | REMOVE BRIDGE FROM CONTROL BOARD A199906657 | |
| TO D1915… | APPARTAMENTO | A199904525 | **NB LOW TENSION CONNECTION |
| *To modify Appartamento low tension to D1915… to high tension | |||
| 1. Use wiring modification file | |||
| 2. Use pressurestat 16A | |||
| 3. Use control board A199906656 | |||
| FROM D1915… | APPARTAMENTO ECO MODE | A199906657 | |
| FROM D1915… | APPARTAMENTO NON ECO MODE | A199906657 | REMOVE CONTROL BOARD BRIDGE |
CELLINI/GIOTTO
- ALL MACHINES TO MAY 2008
TO SERIAL NUMBER 20080500731 INCLUDES UP TO AND ALL PREMIUM MACHINES (MANUFACTURED PRIMARILY BY ECM ITALY)
-110 VOLT USE CONTROL BOARD A 190004276
-ALSO REPLACE WIRING LOOM, PART NUMBER A 190004274
- MACHINES FROM MAY 2008 T0 JULY 2010
MACHINES SERIAL NUMBER 20080500732 (MAY 2008) TO 20100701977 (JULY 2010)
-110 VOLT USE CONTROL BOX A 190004276
- MACHINES FROM JULY 2010
MACHINES SERIAL NUMBER 20100701978 (JULY 2010 TO……)
-110 VOLT USE CONTROL BOARD A 190004525
